Diamondview DV55RM5 - Page 44

44
Main Item
Control Item
CMD
Type
Value/Reply
(Decimal)
Value/Reply
(HEX)
Content
CMD
(HEX)
Remark
4
04
Dual View
7
07
Quad View
PIP source
selection
PIN
W/R
(refer to
MIN)
(refer to MIN)
Select the input source
of sub window 1 (refer to
MIN)
50 49 4E
PIO W/R
(refer to
MIN)
(refer to MIN)
Select the input source
of sub window 2 (refer to
MIN)
50 49 4F
PIP W/R
(refer to
MIN)
(refer to MIN)
Select the input source
of sub window 3 (refer to
MIN)
50 49 50
PIP position PPO W/R
0
00
PIP Position Bottom
-left
50 50 4F
1
01
PIP Position Bottom-
Right
2
02
PIP Position Top
-left
3
03
PIP Position Top
-right
PIP/Main
Swap
SWA
W 0
00
Swap main and PIP
53 57 41
Other
Control
Scaling
ASP W/R
0
00
Native
41 53 50
1
01
Full Screen
2
02
4:3
3
03
Letterbox
PAS W/R
1
01
Full Screen
50 41 53
2
02
4:3
3
03
Letterbox
ZOM W/R 0~10
00~0A
Adjust over
scan ratio
5A 4F 4D
Baud Rate
Adjustment
BRA W/R
0
00
115200
42 52 41
1
01
38400
2
02
19200
Power
Saving
WFS W/R
0
00
Eco
57 46 53
1
01
Normal
2
02
Never Sleep
