15.5.2.3.Flat Mistral model
The scale is fitted with a cartridge system to facilitate the job of changing the paper in the labelling
machine.
1. Open the right hand side drawer of the machine
2. You will then see three blue levers. Turn the lever on the top anticlockwise to release the cartridge.
3. Remove the cartridge roll to change the paper
Having removed the cartridge, you must open the other two levers in order to remove the old paper holder
and remove the remaining cardboard.
4. Proceed to change paper as in the previous section (images 4,5,6).
5. Last of all, place the cartridge in the scale and turn the lever on the top clockwise.
2
3
5
15.5.2.4.Hanging Model
A)
To replace continuous paper :
1.Open the cover of the printer. Remove the spent roll.
2. Fit the new roll as shown in the photo. Ensure that the heat-sensitive side of the paper is in contact
with the head (if not, receipts will come out blank).
3. Press Shift and print in order to place the recipt paper properly.
4. Finally, Close the printer
1
4
