7.1. ETHERNET COMMUNICATION PARAMETER
[ 5 1 ]
If ETHERNET TCP/IP communication is to be used, the next step
is programming ETHERNET COMMUNICATION.
7.1.1.Configure the Scale’s IP Address [ 5 1 1 ]
1. Access to the configuration of scale’s IP address by pressing
the MENU (2 seconds) 5 1 1 keys.
2. Enter the IP address in groups of three characters. Press X
after the third character. E.g.: 010. X 001. X 002. X 155
3. Press ∗
∗∗
∗ to save.
4. Press MENU (2 seconds) to quit the programming menu.
7.1.2.Configure the PC’s IP Address [ 5 1 2 ]
1. Access to the configuration of PC’s IP address by pressing
the MENU (2 seconds) 5 1 2 keys.
2. Enter the IP address of the PC to which the scale is to be
connected in groups of three characters. Press
X
after the
third character. E.g.: 010.
X
001.
X
002.
X
154
3. Press ∗
∗∗
∗ to save.
4. Press MENU (2 seconds) to quit the programming menu.
7.1.3.Equipment Number [ 5 1 3 ]
1. Access to the number of equipment by pressing the MENU
(2 seconds) 5 1 3
2. Program the equipment number, with a number between 00
and 99.
3. Press ∗
∗∗
∗ to save.
4. Press MENU (2 seconds) to quit the programming menu.
7.1.4.Configure the TCP TX Port [ 5 1 4 ]
1. Access to the configuration of the TX port by pressing the
MENU (2 secons) 5 1 4
2. Program Tx TCP port=3001 (always)
3. Press ∗
∗∗
∗ to save.
Press MENU (2 seconds) to quit the programming menu.
