6.5. TRACEABILITY [ 4 5 ]
Articles that are defined with traceability belong to a class or type,
such as meat, fish, fruit…
A general text table has to be created for these classes in order to
define the text that is common to each class. For example,
slaughtered in:, caught in: produced in…
Every master scales have a table with 200 text lines, which will be
referred to as a text table, with lines of different lengths up to 32.
The properties or characteristics of the article are then entered,
and up to 20 text lines can be added with different characteristics
The process to programme texts and animals with general
traceability is as follows:
Press MENU (2 seconds).
In programming mode, the selected option is shown in black. Use
F2 and F1 respectively to go up and down through the menu
options.
Select option 4 Texts. Press
∗
∗∗
∗
and in this menu select option 5
Traceability. Press
∗
∗∗
∗
To exit the programming mode press MENU (2 seconds)
6.5.1.Definition of PLU Class
Program the PLU fields pressing on MENU 1 (See 3.1.1
Creating/ Modifying a PLU). For example, choose the PLU 2 and
press F2 until you find the field CLASS.
1. Class*: We define if the article has or not traceability.
Class = 0: Article without traceability. Press
∗
∗∗
∗
to end PLU
programming
Class ≠
≠≠
≠ 0: Traceability. The class to which the PLU
belongs is assigned here. There are 2* different classes.
Select the class 1
Press the key X in order to go on with the programtion:
2. IDN*: Introducing in the keypad the Identification Number
Product (IDN), as a number with a range from 1 to 20*.
Enter the Identification Number Product with the numeric
keyboard. For example 2.
Press ∗
∗∗
∗ to memorised the article with traceability, which has
already programmed.
** EAN 13 Reading:
Models: W-020, W-025, M-520 & M-525.
* Class:
W-010, W-015 & M-510,M-515 Max 1
W-020, W-025 & M-520,M-525 Max 2
* NRP:
W-010, W-015 & M-510,M-515 Max 10
W-020, W-025 & M-520,M-525 Max 20
