Digi DC-180 - Unlocking Procedure for 1-2.5 lb Scales

11
Do not unplug remote scale from the DC-180 while the DC-180 is powered.
3.4. Unlocking Procedure (Continued) for 1LB. and 2.5LB. Scales
The above drawing is for illustration
purpose only.
SET UP PROCEDURES
Do the following steps before
scale calibration or operation.
1. Take off nut (A) and four screws (C), then take off plate.
2. Loosen nut (B) and screw (D) , then take off screw (D) , nut (B) and insert.
3. Take off screw (E) and stopper, then take off screw (F).
4. Install platter support and platter.
(Please pay attention to installation direction of support.)
Warning!
Do Not Turn Scale Upside Down.
DISCONTINUED
