Digi DC-180 - Specification List

23
7.5. DC-180 Spec. List Rev. 7
Operation Specifications : To enter this mode, enter the numeric keys 1,4,1 while pressing the Rezero
Key.
Spec No. Bit 3 Bit 2 Bit 1 Bit 0
0
1 Power Auto Off Function
0000 : Auto Power Off Disable when Net Wt. = 0
0001 ~ 1111 : Time duration to activate Power Off, equal to the
decimal no. converted from the 4 binary digits
2 Scale Specification
00 : Gram 01 : Kg
10 : Lb 11 : not used
K
g
/Lb Lam
p
Inhibit
0 : No 1 : Yes (ver 1.04)
3 Not used Not used Not used Not used
4 Auto Scale Switching
0 : No 1 : Yes
(ver 1.25)
Extent of insufficient samples
00 : 0.1 %
01 : 0.2%
10 : 0.0%
Negative
Counting
0 : No
1 : Yes
5 Sampling time for Unit
Weight Calculation
0 : 10 times
1 : 5 times
Unit Wt. Auto
Recomputing
0 : No
1 : Yes
6 Display Accuracy of Unit
Weight
0 : No1 : Yes
FIP Brightness Levels
Varying levels for the control of FIP Brightness.
000 : Highest Brightness Level
111 : Lowest Brightness Level
7 Set Point Buzzer
0 : Yes 1 : No
Set Point Type
00 : %Quantity 10 : Quantity
01 : %Weight 11 : Weight
8-9 Not used Not used Not used
(ver 1.06)
Not used
(ver 1.06)
10 RS-232C Connection
0 : No
1 : Yes
(ver 1.07)
RS-232C
Data Length
(Optional)
0 : 7 bits
1 : 8 bits
(ver 1.07)
RS-232C Baud Rate
(Optional)
00 : 1200 10 : 4800
01 : 2400 11 : 9600
(ver 1.07)
11 RS-232C
Stop Bit
(Optional)
0 : 1 bit
1 : 2 bits
(ver 1.07)
RS-232C Parity Bit
(Optional)
00 : No 10 : Not Used
01 : Odd 11 : Even
(ver 1.07)
12 RS-232C Output
(Optional)
00 : Not Available
01 : When Counting Condition
10 : By ∗∗
∗∗
Key
11 : In Both Cases
(ver 1.07)
RS-232C
Communication
0 : With
Handshaking
1 : Without
Handshaking
(ver 1.12)
RS-232C Header
0 : With
Header
1 : Without
Header
(ver 1.12)
13-17 Not used Not used Not used Not used
18 Set Point TTL Output
0: Active Low
1: Active High
(ver 1.08)
Not used Not used Not used
