6.1.3. Set Point Programming by Upper and Lower Limit of Quantity
Set Point 1 : Quantity (See Note Below), Set Point 2 : Quantity (See Note Below)
Set bit 0 and 1 of Spec 7 to 10
1 Display in the weighing mode
2 Press the [MODE] key to go into the programming mode.
3 Press [++
++
] key to go into Set Point Programming Mode.
4 Enter the Quantity value for Set Point 1 using the [Numeric] keys. Example: type
[2][0][0][0][0] Please see the note below.
5 Press the [++
++
] key to program Set Point 2.
6 Enter the Set Point 2 value using the [Numeric] keys. Example: type [1][0][0][0][0]
Please see note below.
7 Pressing the [++
++
] key exits from the Set Point Programming mode, but remains in the Programming
mode.
8 Pressing the [MODE] key exits from Programming mode and returns to Weighing mode.
Note : Set Point 1 : Must be a quantity value up to 999999
Set Point 2 : Quantity value up to 999999, but Set Point 2 value must always be less
than Set Point 1 value.
6.1.4. Set Point Programming by Upper and Lower Limit of Weight
1 Display in the weighing mode
2 Press the [MODE] key to go into the programming mode.
3 Press [++
++
] key to go into Set Point Programming Mode.
4 Enter the Weight value for Set Point 1 using the [Numeric] keys depending on the capacity of the
scale. Example: type [3][.][0][0][0][0] Please see the note below.
5 Press the [++
++
] key to program Set Point 2.
6 Enter the weight value for Set Point 2 using [Numeric] keys. Example: type [2][.][0][0][0][0]Please
see the note below.
7 Press the [++
++
] key exits from the Set Point Programming mode but remains in the Programming
mode.
8 Pressing the [MODE] key exits from Programming mode and returns to Weighing mode.
Note : Set Point 1 : Must be a weight value depending on the capacity of the scale.
Set Point 2 : Weight value up to the capacity of the scale, but Set Point 2 value
must be less than Set Point 1 value.
DISCONTINUED
