Digigram VX222v2 - Cable Pinout Details

D i g i g r a m
32
CABLE PINOUT
Pin # ANALOG DIGITAL
1 R OUT + GPI OUT 1A
2 GND NC
3 L OUT - NC
4 GND AES/EBU IN -
5 NC AES/EBU IN +
6 R IN - GPI INPUT 2
7 L IN + GND/GPI INPUT COMMON
8 GND GPI INPUT 1
9 R OUT - GND
10 L OUT + NC
11 GND GPI OUT 1B
12 NC GPI OUT 2A
13 R IN + GPI OUT 2B
14 GND AES/EBU OUT +
15 L IN - AES/EBU OUT -
