Digigram VX222v2 - Digital Cable Diagram; Digital Cable Wiring with GPIOs

VX222 v2
User’s Manual
31
DIGITAL CABLE DIAGRAM
WIRING DIAGRAM – Digital Cable with GPIOs
J12
male
+
-
3
2
1
AES/EBU OUT
J11
female
+
-
3
2
1
AES/EBU
SYNC/IN 1
1
2
9-pin
SubD
Signal Number
1
11
12
13
8
6
5
4
14
15
J3
XLR
4
5
6
9
3, 7, 8
GPI OUT 1A
GPI OUT 1B
GPI OUT 2A
GPI OUT 2B
GPI IN 1
GPI IN 2
J10
female
shield
