VX222
v2
User’s Manual
7
It is possible to use the signal on the digital input as reference sampling
clock for recording / playback on the analog I/Os.
• 1 digital AES/EBU
∗∗
stereo output
Always plays the digital version of the analog outputs 1 and 2.
• 1 mini jack headphone stereo output
This output is in parallel of the analog outputs 1 and 2.
• 2 general purpose inputs and 2 outputs (GPIO).
• Inter-card synchronization connector.
If this connector is not used, synchro switches must be ON.
If it is used, one of the connected cards must have the synchro switches
ON, all the other linked cards must have the switches OFF.
HARDWARE REQUIREMENTS
• One free PCI slot (5 V or 3.3 V)
• Minimum Apple Macintosh configuration:
PowerMac G3, G4 or G5 with 128 MB RAM.
• Minimum PC configuration:
Pentium III (or equivalent), 128 MB RAM.
SOFTWARE REQUIREMENTS
The VX222v2 requires installation of the drivers included in VX kit 5.0 or
higher. Certain applications designed by Digigram partners may require some
particular driver, such as np Runtime 6.01 or higher. For more information,
please contact your software vendor.
Supported operating systems
Mac OS 10.1 and higher
Windows 98 SE, Windows ME, Windows 2000, XP
*
, and Windows Server 2003
∗
∗∗
can be used as S/PDIF interface as well
∗
32-bit version
