DG-BG1000 User Manual
70
The page shown in the following figure appears.
The following table describes the parameters and buttons of this page:
Parameter Description
IP QoS Select to enable or disable IP QoS function. You need
to enable IP QoS if you want to configure the
parameters of this page.
QoS Policy You can choose stream based, 802.1p based, or
DSCP based.
Schedule Mode You can choose strict prior or WFQ (4:3:2:1).
Source IP The IP address of the source data packet.
Source Mask The subnet mask of the source IP address.
Destination IP The IP address of the destination data packet.
Destination
Mask
The subnet mask of the destination IP address.
