DG-BG1000 User Manual
71
Parameter Description
Source Port The port of the source data packet.
Destination Port The port of the destination data packet.
Protocol The protocol responds to the IP QoS rules. You can
choose TCP, UDP, or ICMP.
Physical Port The LAN interface responds to the IP QoS rules.
Set priority The priority of the IP QoS rules. P0 is the highest
priority and P3 is the lowest.
IP Precedence You can choose from 0 to 7 define the priority in the
ToS of the IP data packet.
IP ToS The type of IP ToS for classifying the data package
You can choose Normal Service, Minimize Cost,
Maximize Reliability, Maximize Throughput, or
Minimize Delay.
802.1p You can choose from 0 to 7.
delete Select a row in the QoS rule list and click it to delete
the row.
delete all Select all the rows in the QoS rule list and click it to
delete the rows.
