DG-WA30002NP User Manual
Authentication Mode: The wireless security authentication
mode of this Access Point will be displayed here. If you
don’t enable security function of the Access Point before
WPS is activated, the Access Point will auto set the
security to WPA (AES) and generate a set of passphrase
key for WPS connection.
Passphrase Key: Displays the WPA passphrase here, all
characters will be replaced by asterisk for security reason.
If encryption is not set on this Access Point, nothing will
be displayed here.
Config Mode There are ‘Registrar’ and ‘Enrollee’ modes for the WPS
connection. When ‘Registrar’ is enabled, the wireless
clients will follow the Access Point’s wireless settings for
WPS connection. When ‘Enrollee’ mode is enabled, the
Access Point will follow the wireless settings of wireless
client for WPS connection.
Start PBC Click ‘Start PBC’ to start Push-Button style WPS setup
procedure. This Access Point will wait for WPS requests
from wireless clients for 2 minutes. The ‘WLAN’ LED on
the Access Point will be steady on for 2 minutes when this
Access Point is waiting for incoming WPS request.
Start PIN Please input the PIN code of the wireless client you wish
to connect, and click ‘Start PIN’ button. The ‘WLAN’
LED on the Access Point will be steady on, when this
Access Point is waiting for incoming WPS request.
NOTE: When you’re using PBC type WPS setup, you must press ‘PBC’
button (hardware or software) of wireless client within 120
seconds. If you didn’t press PBC button of wireless client within
this time period, please press ‘PBC’ button (hardware or software)
of this Access Point a
