Product Description 1-5
Front and Back Panel Components
4 EIA/TIA 423
(Asynchronous serial ports)
DECserver 716 Only: 16 asynchronous device 8-Pin MJ
ports for connections.
DECserver 732 Only: 32 asynchronous device 8-Pin MJ
ports for connections.
5 Seven-segment Display Provides error and status information.
Blinks: If an error occurs during self-test.
Off: The DECserver 716 or 732 has failed self-test.
Rotating Figure’8’: Operating image loaded and running.
6 10BASE-T and AUI
selector switch
Allows you to switch between the 10BASE-T and AUI port
on the server.
Up: 10BASE-T port is selected.
Down: AUI port is selected.
7 Ethernet Address
(MAC Address Label)
Used for Ethernet address label. This area is where the
MAC Address Label resides.
8 10BASE-T Port connection Ethernet connection used to connect to a 10BASE-T
network via a RJ45 connector.
9 AUI Selection LED On: AUI port selected.
Off: No AUI port selected.
10 10BASE-T Selection LED On: 10BASE-T port selected.
Off: No 10BASE-T port selected.
11 LNK LED On: Ethernet connection to a 10BASE-T connection or the
AUI port is selected.
Off: No Ethernet connection to a 10BASE-T connection
and no AUI port selected.
12 AUI Port Ethernet connection via an AUI port connection.
Item Name Description
