Connecting and Removing Cables and Adapters 5-1
Chapter 5
Connecting and Removing Cables and
Adapters
Overview
Introduction
This chapter describes how to connect cables to and remove cables from the
DECserver 716 or DECserver 732.
For cable lengths, refer to Chapter 4, Cabling Requirements. For information on
connectors, refer to Appendix B, Connector and Pin Assignments.
NOTE
The term DECserver is used where information is common to both the DECserver
716 and the DECserver 732.
In This Chapter
Topic Page
Connecting the Console Cable 5-3
Connecting Cables 5-4
Connecting the 8-Pin MJ Cable 5-3
Connecting the 10BASE-T (UTP) Cable 5-5
Connecting the Ethernet AUI Adapters 5-6
Cabling the Ethernet AUI Adapters 5-7
Connecting the Power Cable 5-10
Removing the Cables 5-11
