Views of Projector Parts
Front-right View
ITEM
LABEL
DESCRIPTION
SEE PAGE:
1.
Vent
Cool air intake.
2.
Tilt Adjuster
Rotate adjuster lever to adjust angle position.
19
3.
Lens Release Button
For release Lens.
14
4.
Anti-dust cap
Anti-dust cap
5.
IR Receiver
Receives IR signal from remote control.
7
6.
LEDs
Displays the projector status.
3
7.
Lens Shift
Adjusts the image position.
20
Important:
Ventilation openings on the projector allow for good air circulation, which keeps the projector light
source cool. Do not obstruct any of the ventilation openings.
1 2 3 4 2 1
7
5 6 5
