Removing the Existing Lens From the Projector
1.
Push the LENS RELEASE button to
the unlock position.
2.
Grasp the lens.
3.
Rotate the lens counterclockwise.
The existing lens will be
disengaged.
4.
Pull out the existing lens slowly.
