Digital Projection

E-Vision Laser 6500 Series User Manual

Rev B August 2017

— 77 —

Command Group 02

ASCII

HEX

Function

Description

Return Value

VXXS0201

56h Xh Xh 53h 30h 32h 30h 31h 0Dh

Select RGB

P/F

VXXS0203

56h Xh Xh 53h 30h 32h 30h 33h 0Dh

Select DVI

P/F

VXXS0204

56h Xh Xh 53h 30h 32h 30h 34h 0Dh

Select Video

P/F

VXXS0206

56h Xh Xh 53h 30h 32h 30h 36h 0Dh

Select HDMI

P/F

VXXS0207

56h Xh Xh 53h 30h 32h 30h 37h 0Dh

Select BNC

P/F

VXXS0209

56h Xh Xh 53h 30h 32h 30h 39h 0Dh

Select HDMI 2

P/F

VXXS0213

56h Xh Xh 53h 30h 32h 31h 33h 0Dh

Select HDBaseT

P/F

VXXG0220

56h Xh Xh 47h 30h 32h 32h 30h 0Dh

Get Current Source

Return

1:RGB

3:DVI

4:Video

6:HDMI

7:BNC

9:HDMI2

13:HDBaseT

Pn/F

Command Group 03

ASCII

HEX

Function

Description

Return Value

VXXG0301

56h Xh Xh 47h 30h 33h 30h 31h 0Dh

Get Scaling

0:Fill

1:4:3

2:16:9

3:Letter Box

4:Native

5:2.35:1

Pn/F

VXXS0301n

56h Xh Xh 53h 30h 33h 30h 31h nh 0Dh

Set Scaling

0:Fill

1:4:3

2:16:9

3:Letter Box

4:Native

5:2.35:1

P/F

VXXG0302

56h Xh Xh 47h 30h 33h 30h 32h 0Dh

Blank

Pn/F

VXXS0302n

56h Xh Xh 53h 30h 33h 30h 32h nh 0Dh

Blank

P/F

VXXG0304

56h Xh Xh 47h 30h 33h 30h 34h 0Dh

Freeze On

Pn/F

VXXS0304n

56h Xh Xh 53h 30h 33h 30h 34h nh 0Dh

Freeze On

P/F

VXXG0305

56h Xh Xh 47h 30h 33h 30h 35h 0Dh

Volume

n=0~10

Pn/F

VXXS0305n

56h Xh Xh 53h 30h 33h 30h 35h nh 0Dh

Volume

n=0~10

P/F

VXXG0308

56h Xh Xh 47h 30h 33h 30h 38h 0Dh

Projection Mode

0:Front

1:Rear

2:Ceiling

3:Rear+Ceiling

Pn/F

VXXS0308n

56h Xh Xh 53h 30h 33h 30h 38h nh 0Dh

Projection Mode

0:Front

1:Rear

2:Ceiling

3:Rear+Ceiling

P/F

VXXG0309

56h Xh Xh 47h 30h 33h 30h 39h 0Dh

Set vertical keystone

value

n=-30~+30

Pn/F

VXXS0309n

56h Xh Xh 53h 30h 33h 30h 39h nh 0Dh

Set vertical keystone

value

n=-30~+30

P/F

VXXG0310

56h Xh Xh 47h 30h 33h 31h 30h 0Dh

Set horizontal

keystone value

n=-25~+25

Pn/F

VXXS0310n

56h Xh Xh 53h 30h 33h 31h 30h nh 0Dh

Set horizontal

keystone value

n=-25~+25

P/F
