5.8.3.1 PTZ control
After finishing the PTZ setup, you can use the PTZ function to control your PTZ camera.
1) Left click your mouse upon a channel on Live Viewing screen to open Camera Quick Toolbar,
and click the PTZ control icon .
2) PTZ control panel will be displayed. Click to active PRESET points setup page.
No. Icon Item Description
1 Channel Click to select the channel of the PTZ camera.
2
Cruise
Start/stop PTZ cruise by preset points. Make sure you had
enable the Cruise function for this channel in
5.8.3 PTZ Setup & Control
3 UTC Menu
If you have choose protocol for this channel as COAX1 or
COAX2, the UTC menu button will be display. Click this icon
to enter UTC OSD menu. Also used to confirm your selection
in the UTC OSD menu.
4 Speed Speed Adjust the PTZ speed
5 Pointer Panel
A) Click the direction arrow to select the direction of the PTZ
camera
B) Click up/down/left/right arrow to move cursor in UTC OSD
menu
C) Click to switch to auto pan mode
1 2 3 4 7 8 9
14
5
6 10 11 12
13
