DINGO 150 User Manual

15. Pay attention at fixation method of a side footboard in a back part of the
snowmobile (the footboard should be inserted in a frame groove).
17. Take off a chain cover. Pay attention at a cover holder (it is highlighted in green in the
photo).
11
16. … in the front part of the snowmobile.
18. With a 19 key wrench loosen a nut of a
chain tensioner.
ASSEMBLY / DISASSEMBLY PROCEDURE
