Directed Electronics Automate AM5

To Next Page

To Previous Page

Table of zones

Zone

number

Trigger type Input description

1 Instant trigger Hood and/or trunk pin switches.

Blue (H1/7) wire)

2 Multiplexed input Heavy impact from onboard Double-

gurard® shock sensor.

3 Door trigger Green (H1/8) and Violet (H1/6)

4 Multiplexed Lt. Blue (H2/2) wire. Optional sen-

sor, Inputs shorter than 0.8 seconds

triggers Warn Away® response,

while inputs longer than 0.8 sec-

onds instantly trigger full alarm.

5 Ignition input Yellow (H1/4) + ignition wire.

Note:

The WarnAway repsonse does not report on the LED.

Directed Electronics Automate AM5 - Table of Zones
