➤ Auxiliary harness (H2)

H2/1

BROWN (-) HORN HONK OUTPUT

This wire supplies a 200 mA (-) output that can be used to honk the

vehicle’s horn. It provides a pulsed output when the security system is

armed/disarmed and in the triggered sequence or in panic mode. In

most vehicles with (-) horn circuits this wire can control the vehicle’s horn

without adding a relay. If the vehicle has a (+) horn circuit, an optional

relay must be used to interface with the vehicle’s horn circuit.

Warning:

Never use this wire to drive anything but a

relay or a low-current input. Transistorized output can only

supply (-) 200 mA. Connecting directly to a solenoid,

motor, or other high-current device will cause the module

to fail.

H2/2

LT. BLUE (-) MULTIPLEX INPUT (ZONE 4)

This input responds to a negative input with Warn Away or instant trig-

ger. It can be used with Directed dual-stage sensors. It can also be used

for hood and trunk pins and reports Zone 4.
