H2/3

WHITE/VIOLET (-) 200mA AUX 1 OUTPUT

This wire provides 200 mA programmable output whenever the transmitter but-

ton controlling Aux 1 channel is pressed. (See descriptions for Aux 3)

Warning! Never use this wire to drive anything

but a relay or a low-current input, supplied

output is only 200mA. Connecting directly to

a solenoid, motor, or other high-current device

will cause the module to fail.

H2/4

VIOLET/BLACK (-) 200mA AUX 2 OUTPUT

This wire provides 200 mA programmable output whenever the transmitter but-

ton controlling Aux 2 channel is pressed. (See descriptions for Aux 3.)

Warning! Never use this wire to drive anything

but a relay or a low-current input, supplied out-

put is only 200mA. Connecting directly to a

solenoid, motor, or other high-current device will

cause the module to fail.

H2/5

WHITE/BLACK (-) 200mA AUX 3 OUTPUT

This wire provides 200 mA programmable output whenever the transmitter but-

ton controlling Aux 3 is pressed. This output can be programmed to provide the

following types of outputs

Validity: Output that sends a signal as long as the transmission is re-s

ceived.

Latched: Output that sends a signal when the Aux channel button is pressed s

and continues until the same button is pressed.
