58
© 2008 Directed Electronics. All rights reserved.
Shutdown diagnostics
To perform shutdown diagnostics:
With the ignition OFF, press and hold the Valet/Program switch.1.
Turn the ignition ON and then back OFF while holding the Valet/Pro-2.
gram switch.
Release the Valet/Program switch.3.
Press and release the Valet/Program switch. The LED flashes to report 4.
the last shutdown for one minute or until the ignition is turned on, as
shown in the following table:
LED Flashes Shutdown mode
1 Runtime expired
2 Over-rev shutdown
3 Low or no RPM
4 Transmitter shutdown (or optional
pushbutton)
5 (+) Brake shutdown
6 (-) Hood shutdown
7 Timer mode/Turbo mode/Manual
mode error *
8 Neutral safety shutdown
9 Low battery (voltage mode)
10 -------------------------------------------------------
11 Wait-to-start input timed out
* Timer mode error: Ignition is on or shutdown input is active when activating
timer mode.
Turbo mode error: Turbo mode is programmed off, engine is not on or
shutdown input is active.
Manual mode error: MTS mode not enabled.
