¢Heavy Gauge, 8-pin connector
There are 8 heavy gauge wires coming from the large 8-pin connector. They
are used to energize the ignition circuits in the vehicle. It is crucial to ensure that
these connections are capable of handling the current demands. For this reason,
Scotch-Locks, T-taps and other such connectors are strongly discouraged.
H3/1
PINK (+) IGNITION 1 INPUT/OUTPUT
Connect this wire to the ignition wire in the vehicle. This wire not only supplies
voltage for the ignition line in the vehicle, it is also the ignition feed for the remote
start system.
H3/2
RED/WHITE (+) FUSED (30A) IGNITION 2 / FLEX RELAY INPUT 87
This wire is the polarity feed for the ignition 2/flex relay.
H3/3
ORANGE ACCESSORY OUTPUT
Connect this wire to the accessory wire that powers the climate control system
H3/4
VIOLET STARTER OUTPUT
Connect this wire to the starter wire in the vehicle.
H3/5
RED (+) FUSED (30A) IGNITION 1 INPUT
This wire is the polarity feed for the Ignition 1 relay.
H3/6
PINK/WHITE IGNITION 2 / FLEX RELAY OUTPUT 30
This wire is factory programmed as Ignition 2 and can be programmed as a
2nd accessory or 2nd starter.
