2-13 Aux 3 Linking None (1)

Lock (2) Unlock (3) Lock/Unlock (4) Smart key

control (link to remote start Off. (5). When aux 3 is programmed to Smart Key

control, this wire outputs a 800ms pulse when the Remote Start is shut Off.

The system also monitors the door trigger input. When the door is opened dur-

ing the remote start runtime, the remote start shuts down and this wire outputs

the 800ms pulse.

Important:

This wire is connected to the pushbutton wire that start

and stops the car. It pulses the wire at the button to shut off the

car when the remote start is deactivated.

¢ Menu 3 - Remote start

3-1 Manual Transmission Mode:

This is the default setting. The two-honk setting

is used for Automatic transmission mode. In the default setting the remote start

unit is programmed to look for a shutdown procedure to activate the remote

start.

Important:

The optional door input has to be connected for

manual transmission start to work.

3-2 Engine Checking Virtual Tach:

(1) When set to “virtual tach” the remote

start will monitor the cranking voltage of the vehicle and set that voltage as a

reference point. Fifteen seconds after the crank output sequence the remote start

checks the voltage again to determine if the vehicle is running.

When set to voltage (2), the unit cranks the starter for the programmed time and

then senses that the engine is running by detecting an increase in voltage. If

programmed OFF (3) the vehicle cranks for the programmed time and does not

verify with tach or any voltage setting that the car is running. If the vehicle fails

to start, the ignition will stay on for the run duration. Using tach or either voltage

settings is recommended.

When set to Tachometer (4), the unit references the learned tach signal to disen-

gage the starter. In addition it will monitor the RPM and shut down if the engine

RPM is too high or too low.

Important:

The tach wire must be connected and programmed

for the manual transmission mode to work.
