memory, and continues to chirp four or five times each time it is dis-
armed, until the next time the ignition key is turned on.
Table of Zones
A zone is represented by the number of control center LED flashes used
by the system to identify a particular type of input. Standard input as-
signments are listed in the following table, along with spaces to write in
any optional sensors or switches that have been installed.
Zone Description Dealer installed options
1 Trunk Pin
2 Instant trigger: a heavier impact detected by the
shock sensor
3 Door switch trigger
4 Instant trigger: for optional sensors
5 Ignition trigger
6 Hood Pin
Interpreting Zone Diagnostics
Warn Away responses are not reported by arming or disarming diag-
nostics. If you receive a Bypass notification when arming or a Tamper
Alert notification when disarming, look at the LED in the vehicle. Active
or triggered zones will be indicated by a pattern of blinks by the LED.
For example: If zone 3 was active or triggered, the LED will blink three
times with a two-second pause. Then it will blink three times again, and
repeat until the ignition is turned on.
Your system stores the last two triggered zones in memory. If your system
has been triggered but the LED has been reset by turning on the igni-
tion, your dealer can still recall the last two zones that were triggered.
Contact your dealer for details.
