Directed 5305V - LCD Icons at a Glance

4
© 2015 Directed. All rights reserved.
LCD Icons at a Glance
123 4 5
6
7
8
9
10
12
11
13
14
15
16
17
18
Item Description Item Description
1 Transmit 10 Battery level indicator
2 Out of range 11 Remote start
3 Receive 12 Remote sending
4 Aux channels & alarm zones 13 Vibrate mode
5 Warn away 14 Ignition
6 Audible mode 15 Vehicle number
7 Alarm 16 Door
8 Trunk or Hood 17 Arm
9 Sensor 18 Disarm
