Directed XpressKit - Wiring Reference Chart - Type 3

Rev.: 20 708115
Platform: DBALL2
Firmware TL6:
© 201 Directed.7 All rights reserved.
Page 10
Vehicle - 3Wiring Reference Chart Type
Function Color Pin Polarity Location Color Pins
HS CAN High Blue 6 Data Located at OBDII. Black 16
HS CAN Low White 14 Data Located at OBDII. Black 16
BTX Blue 25 Data Middle connector Body ECU on dash fuse box. White 30
BRX Red 26 Data Middle connector Body ECU on dash fuse box. White 30
Autolight Green 28 Cut Middle connector Body ECU on dash fuse box. White 30
12V Blue 16 (+) Located at OBDII. Black 16
Lock Red 11 (-) Middle connector Body ECU on dash fuse box. White 30
Unlock Gray 24 (-) Middle connector Body ECU on dash fuse box. White 30
Parking Lights White 30 (-) Middle connector Body ECU on dash fuse box. White 30
PTS Violet 17 (-) Power Management ECU left of dash fuse box. Gray 31
SLP Pink 4 (-) Steering Lock under steering column. Black 7
Trunk Release Red 5 (-) Bottom connector Body ECU on dash fuse box. White 28
Wire Information Connector Information
Lexus ES 300h (Smart Key) 2013-2015
