Directed XpressKit User Manual

Rev.: 20 708115
Platform: DBALL2
Firmware TL6:
© 201 Directed.7 All rights reserved.
Vehicle - 4Wiring Reference Chart Type
Page 12
Function Color Pin Polarity Location Color Pins
HS CAN High Blue 6 Data Located at OBDII. White 16
HS CAN Low White 14 Data Located at OBDII. White 16
BTX
Brown 25 Data Body ECU on dash fuse box. White 30
BRX
Lt. Green 26 Data Body ECU on dash fuse box. White 30
Autolight Tan 28 Cut Body ECU on dash fuse box. White 30
12V Red 16 (+) Located at OBDII. White 16
Parking Lights Red 30 (-) Body ECU on dash fuse box. White 30
PTS Violet 1 (-) Push-to-Start Switch. Black 10
SLP Green 4 (-) Steering Lock under steering column. Black 7
HS CAN High Blue 6 Data Located at OBDII. White 16
HS CAN Low White 14 Data Located at OBDII. White 16
BTX
Brown 25 Data Body ECU on dash fuse box. White 30
BRX
Lt. Green 26 Data Body ECU on dash fuse box. White 30
Autolight Tan 28 Cut Body ECU on dash fuse box. White 30
12V Red 16 (+) Located at OBDII. White 16
Parking Lights Red 30 (-) Body ECU on dash fuse box. White 30
PTS Violet 1 (-) Push-to-Start Switch. Black 10
SLP Green 4 (-) Steering Lock under steering column. Black 7
HS CAN High Blue 6 Data Located at OBDII. White 16
HS CAN Low White 14 Data Located at OBDII. White 16
BTX
Green 25 Data Body ECU on dash fuse box. White 30
BRX
Red 26 Data Body ECU on dash fuse box. White 30
Autolight Green 28 Cut Body ECU on dash fuse box. White 30
12V Red 16 (+) Located at OBDII. White 16
Parking Lights White or Black 30 (-) Body ECU on dash fuse box. White 30
PTS Violet 1 (-) Push-to-Start Switch. Black 10
SLP Pink 4 (-) Steering Lock under steering column. Black 7
HS CAN High Blue 6 Data Located at OBDII. White 16
HS CAN Low White 14 Data Located at OBDII. White 16
BTX Green 25 Data Body ECU on dash fuse box. White 30
BRX Red 26 Data Body ECU on dash fuse box. White 30
Autolight Green 28 Cut Body ECU on dash fuse box. White 30
12V Red 16 (+) Located at OBDII. White 16
Parking Lights White or Black 30 (-) Body ECU on dash fuse box. White 30
PTS Violet 1 (-) Push-to-Start Switch. Black 10
SLP Red 4 (-) Steering Lock under steering column. Black 7
HS CAN High Gray 6 Data Located at OBDII. White 16
HS CAN Low White 14 Data Located at OBDII. White 16
BTX Black 25 Data Body ECU on dash fuse box. White 30
BRX Red 26 Data Body ECU on dash fuse box. White 30
Autolight Red 28 Cut Body ECU on dash fuse box. White 30
12V Lt. Blue 16 (+) Located at OBDII. White 16
Parking Lights Lt. Blue 30 (-) Body ECU on dash fuse box. White 30
PTS Lt. Blue 1 (-) Push-to-Start Switch. White 10
SLP Pink 4 (-) Steering Lock under steering column. Black 7
Toyota Prius C (Smart key) 2012-2014
Toyota Camry Hybrid (Smart Key) 2012-2015
Wire Information Connector Information
Toyota Avalon (Smart Key) 2013-2015
Toyota Camry (Smart Key) 2012-2015
Toyota Avalon Hybrid 2013-2015
