Directed XpressKit User Manual

Rev.: 20 708115
Platform: DBALL2
Firmware TL6:
© 201 Directed.7 All rights reserved.
Vehicle - 8Wiring Reference Chart Type
Page 22
Function Color Pin Polarity Location Color Pins
HS CAN 1 High Red 14 Data Middle connector Body ECU on dash fuse box. White 30
HS CAN 1 Low Gray or White 13 Data Middle connector Body ECU on dash fuse box. White 30
HS CAN 2 High Red 9 Data Bottom 28 pin connector of ECU. White 28
HS CAN 2 Low Gray 10 Data Bottom 28 pin connector of ECU. White 28
BTX Black 25 Data Middle connector Body ECU on dash fuse box. White 30
BRX Green or White 26 Data Middle connector Body ECU on dash fuse box. White 30
Autolight Red 28 Cut Middle connector Body ECU on dash fuse box. White 30
12V Black or White 16 (+) Located at OBDII. Black 16
Parking Lights Black 30 (-) Middle connector Body ECU on dash fuse box. White 30
PTS Green 1 (-)
Push-to-Start Switch. Black 10
SLP Blue 4 (-)
Steering Lock under steering column. Black 7
Trunk Release Yellow 8 (-) Bottom 28 pin connector of ECU. White 28
Wire Information
Connector Information
Lexus G350 (Smart Key) 2016
