Directed XpressKit User Manual

Rev.: 20 708115
Platform: DBALL2
Firmware TL6:
© 201 Directed.7 All rights reserved.
Page 23
Module Programming
Press the ush-to- tart button to turn the ignitionPS()PTS twice
ON LED ON. The green turns for 3 seconds and shuts .OFF
Refer to the Diagnostics section for more information and for troubleshooting purposes.LED
2
1
4
3
Wait until the LED turns solid red.ON
Wait 4 seconds before turning the ignition ON.
The the isLED OEMflashes orange if remote starter detected.
()See page 3 for more information .
If the flashes orange, programming button 5 .LED press the times
The turns solid orange for 3 seconds: the programming is done.LED
Otherwise proceed to the next step.
ENGINE
START
STOP
PUSH 2X
& &
&&
You have successfully completed the module programming sequence.
5
ENGINE
START
STOP
PUSH 1X
Press the button more to turn the ignition .PTS OFFonce
Solid
Flashes
Flashes
Solid x3 Secs Off
Solid x3 sec.Press x5
OR
If required for your installation, connect the 10-pin, 12-pin and 14-pin harnesses to
the module, then connect the 4-pin D2D harness.
D2D Installation
W W Installation2
If required for your installation, connect the 10-pin and 12-pin harnesses to the
module, then connect the 14-pin harness to the module.
10-pin
D2D
1
st
12-pin
14-pin
2
nd
3
rd
10-pin
D2D
1
st
4
th
12-pin
14-pin
2
nd
3
rd
Important
Make all the required connections to the vehicle, as described in the wiring diagram(s) found in this guide, and double check to
ensure everything is correct prior to moving onto the next step.
Warning! To take advantage of advanced features, you must use Xpress 4.5 (and higher) or the Directechs Mobile app.VIP
When the flashing operation is successful, you can proceed with the programming instructions below.
Flashing a module using your computer:
1. Connect the interface module to your computer using the
XKLoader2.
2. Go to www.directechs.com using Internet Explorer, and
select the button.Flash Module
3. Follow the instructions to select your vehicle, installation
type, and configure your options.
4. Once you have configured the firmware options, click on the
FLASH button.
Flashing a module using your smartphone or tablet
1. Connect the interface module to your oader3.XKL
2. Launch the Directechs Mobile app on your smartphone or
tablet.
3. Select and follow the on screenFLASH YOUR MODULE
instructions.
