Rev.: 20 708115

Platform: DBALL2

Firmware TL6:

Page 6

Vehicle -Wiring Reference Chart Type 1

Function Color Pin Polarity Location Color Pins

HS CAN High Blue 6 Data Located at OBDII. Black 16

HS CAN Low White 14 Data Located at OBDII. Black 16

BTX Blue 25 Data Middle connector Body ECU on dash fuse box. White 30

BRX Red 26 Data Middle connector Body ECU on dash fuse box. White 30

Autolight Green 28 Cut Middle connector Body ECU on dash fuse box. White 30

12V Blue 16 (+) Located at OBDII. Black 16

Parking Lights White 30 (-) Middle connector Body ECU on dash fuse box. White 30

PTS Violet 30 (-) Top connector Certification ECU behind glove box. White 30

SLP Pink 4 (-) Steering Lock under steering column. Black 7

Lock Red 11 (-) Middle connector Body ECU on dash fuse box. White 30

Unlock Gray 24 (-) Middle connector Body ECU on dash fuse box. White 30

Trunk Release Red 5 (-) Body ECU on dash fuse box. White 28

Wire Information Connector Information

Lexus ES 350 (Smart Key) 2013-2015

Directed XpressKit User Manual
