Directed XpressKit User Manual

Rev.: 20 708115
Platform: DBALL2
Firmware TL6:
© 201 Directed.7 All rights reserved.
Vehicle - 5Wiring Reference Chart Type
Page 15
Function Color Pin Polarity Location Color Pins
HS CAN High Red 6 Data Located at OBDII. White 16
HS CAN Low White 14 Data Located at OBDII. White 16
12V Green 16 (+) Located at OBDII. White 16
SLP Green 4 (-) Steering Lock under steering column. Black 7
BTX Empty 25 Data Middle connector Body ECU on dash fuse box. White 30
BRX Empty 26 Data Middle connector Body ECU on dash fuse box. White 30
Parking Lights White 30 (-) Middle connector Body ECU on dash fuse box. White 30
Autolight Violet 28 cut Middle connector Body ECU on dash fuse box. White 30
PTS Black 1 (-) Push-to-Start Switch. Black 10
Wire Information Connector Information
Toyota Corolla Smart key 2014-2016
