Function Color Pin Polarity Location Color Pins
HS CAN High Black 6 Data Located at OBDII. Black 16
HS CAN Low White 14 Data Located at OBDII. Black 16
BTX Blue 25 Data Body ECU on dash fuse box. White 30
BRX Red 26 Data Body ECU on dash fuse box. White 30
Autolight Green 28 Cut Body ECU on dash fuse box. White 30
12V Blue 16 (+) Located at OBDII. Black 16
Parking Lights White 30 (-) Body ECU on dash fuse box. White 30
PTS Dk. Green 1 (-) Push-to-Start Switch. Black 10
SLP Green 4 (-) Steering Lock under steering column. Black 7
Wire Information Connector Information
Toyota RAV4 (Smart Key) 2013-2015
