Directed XpressKit - Wiring Reference Chart - Type 2

Rev.: 20 708115
Platform: DBALL2
Firmware TL6:
© 201 Directed.7 All rights reserved.
Page 8
Vehicle - 2Wiring Reference Chart Type
Function Color Pin Polarity Location Color Pins
HS CAN High Pink or White 14 Data Middle connector Body ECU on dash fuse box. White 30
HS CAN Low Violet 13 Data Middle connector Body ECU on dash fuse box. White 30
BTX Black 25 Data Middle connector Body ECU on dash fuse box. White 30
BRX White or Green 26 Data Middle connector Body ECU on dash fuse box. White 30
Autolight Red 28 Cut Middle connector Body ECU on dash fuse box. White 30
12V Yellow 16 (+) Located at OBDII. Black 16
Lock Gray 16 (-) Driver Door Module. White 24
Unlock Violet 24 (-) Driver Door Module. White 24
Parking Lights Black 30 (-) Middle connector Body ECU on dash fuse box. White 30
PTS Green 1 (-) Push-to-Start Switch. Black 10
SLP Blue 4 (-) Steering Lock under steering column. Black 7
Trunk Release Yellow 8 (-) Body ECU on dash fuse box. White 28
HS CAN High Pink or White 14 Data Middle connector Body ECU on dash fuse box. White 30
HS CAN Low Violet 13 Data Middle connector Body ECU on dash fuse box. White 30
BTX Black 25 Data Middle connector Body ECU on dash fuse box. White 30
BRX White or Green 26 Data Middle connector Body ECU on dash fuse box. White 30
Autolight Red 28 Cut Middle connector Body ECU on dash fuse box. White 30
12V Yellow 16 (+) Located at OBDII. Black 16
Lock Gray 16 (-) Driver Door Module. White 24
Unlock Violet 24 (-) Driver Door Module. White 24
Parking Lights Black 30 (-) Middle connector Body ECU on dash fuse box. White 30
PTS Green 1 (-) Push-to-Start Switch. Black 10
SLP Blue 4 (-) Steering Lock under steering column. Black 7
Trunk Release Yellow 8 (-) Body ECU on dash fuse box. White 28
Wire Information Connector Information
Lexus GS 350 (Smart Key) 2013-2015
Lexus GS 450h (Smart Key) 2013-2015
