123
1. SATELLITE IN 1 (SWM-2) – Connect one line from your 5-LNB dish here. A Single Wire Multi-Switch (SWM) connection, if applicable, is
made to this satellite in port.
13. POWER – Your receiver must be plugged in at all times to function properly.
2. SATELLITE IN 2 – Connect the second line from your 5-LNB dish here.
10. USB – For future use.
3. S-VIDEO OUT – An SD output.
4. RCA-Audio/Video Jacks – SD output. You can use the entire row of RCA connectors (yellow, white and red) to feed a VCR or DVD
player/burner.
5. COMPONENT VIDEO OUT– Use this block to connect up component video cables (green, blue, red) and use the white and red RCA
connectors below it for analog audio out.
6. DIGITAL AUDIO OUT COAX – Use this digital audio connection for sound.
7. DIGITAL AUDIO OUT OPTICAL – Use this digital audio connection for sound.
8. HDMI – Use this combination digital video and audio connector for the best picture quality.
9. SATA – Use this connector to add an external hard drive to your receiver.
11. ETHERNET – Connect your home network here to enable DIRECTV on Demand and Media Share features.
12. PHONE JACK – Connect your phone line here to enable Pay Per View purchasing and Caller ID (if your phone service package
includes it).
Appendix 1: Receiver Front and Back Panels
