SK3000 Operator’s Manual Controls - 49
Operator Station Console
6. Parking brake To set, pull.
To release, push.
7. Auxiliary lock switch To lock auxiliary function,
press.
To unlock, press again.
Auxiliary function must be at 80% or
greater in either direction to be
locked. See “High/Low auxiliary
control” on page 48.
Control locks high/low auxiliary
function at 100%.
8. Throttle To increase engine speed,
push.
To decrease, pull.
Control only functions if console
throttle mode is selected. See “Main
Menu” on page 40.
If throttle is not set to low when
engine is started or throttle mode is
changed, it must be returned to low
in order to function.
9. Lift arm control To move lift arms down,
push.
To float, push to end.
To move lift arms up, pull.
To curl attachment up, move
left.
To curl attachment down,
move right.
Item Description IMPORTANT
