Dixie DN720P - SETTING THE VENDER TYPE; Normal Mode Vender Configuration

PROGRAMMING P SERIES
Page 30 of 100
Setting The Vender Type
NORMAL MODE:
Note: If ”COLS” appears on the display on power up with the door open, you will need to program the vender model number
in the controller. To program with “COLS” on the display press select button 4. The display will show “6” for six columns.
Press select button 2 to scroll through available number of columns in the machine. When the displayed number of columns
matches the number of columns in the machine, press select button 4 to set the number of columns. “MODL” will appear on
the display, press select button 4. The display will show the first available model number for the current vender type. Press
select button 2 to scroll through the available vender model numbers for this vender. When the vender type you wish to save
is showing on the display, press select button 4. The display will scroll “4 = SET PACKAGE TYPE; 1 = EXIT”. Press select
button 4 and the display will show “ALL2” with the 2 flashing. This will allow you to set the package type of the machine if it is
different that the default of package type 2. Press select button 2 to scroll through the available package types. Press select
button 4 to set the displayed package type, and the display will show “SAVE”. Press button 4 to save the package type.
“PRM1” will appear on the display. Press button 4 to prime column 1 or select button 1 to skip priming column 1. The display
will then display “PRM2”. Repeat the priming process until all columns have been primed or skipped. The controller will return
to normal door open operating mode.
The following are Non-Coca-Cola model numbers:
6 column machines
DN552-5,
DN552-6,
DN552-7,
DN756-10DP,
7 column machines
DN504-6,
DN504-7,
DN504-8,
DN532-5,
DN532-6,
DN532-7,
8 column machines
DN756-7,
DN756-8,
DN756-9,
DN756-10,
DN756-11,
DN756-12,
DN756-13,
DN756HV-12,
10 column machines
DN720-8, DN720-9, DN720-10,
DN720-12,
DN760-9,
DN760-10,
DN760-11, DN760HV-11
DN760-12, DN760HV-12,
DN760-13,
DN770-12, DN770HV-11, DN770HV-12
The following are other model numbers that may appear:
6 column machines 8 column machines (continued)
DN552-5, DN756-9
DN552-6, DN756-10
DN552-7, DN756-11, DN756HV-11
DN552-8, DN756-12, DN756HV-12
7 column machines DN756-13
DN532-5, 10 column machines
DN532-6, DN760-9
DN532-7, DN760-10
DN532-8, DN760-11
8 column machines DN760-12
DN756-7, DN760-13
DN756-8,
