PARTS LIST P SERIES
Page 77 of 100
INNER DOOR
ITEM
PART DESCRIPTION DN504P DN720P
Inner Door Assembly
Chameleon 640,054,90x.x3 629,050,60x.x3
1
All LMV 640,052,80x.x3 639,053,00x.x3
Inner Door Gasket
2
All 801,819,05x.x1 801,819,04x.x1
Sub Assembly Inner Door
Chameleon 640,054,80x.x3 629,050,50x.x3
3
All LMV 640,050,90x.x3 639,050,50x.x3
Label, Programming 3.0
All Except Italy 803,887,83x.x1 SAME
4
Italy 803,857,71x.x1 NA
Loading Instruction
5
All 803,881,63x.x1 SAME
Wiring Diagram
Chameleon 803,886,64x.x1 803,886,47x.x1
All LMV Except Italy 803,881,74x.x1 803,881,75x.x1
6
Italy 803,886,46x.x1 NA
Label, Button/Stack
Chameleon 803,886,65x.x1 803,886,32x.x1
7
All LMV 803,881,34x.x1 803,881,35x.x1
Gate, Front Product Positioner
Chameleon 801,824,27x.x1 801,821,81x.x1
8
All LMV 801,821,57x.x1 801,821,56x.x1
Discharge Frame Retainer
9
All 801,809,15x.x1 SAME
Assembly, Discharge Frame
10
All 801,809,16x.x1 SAME
Door, Discharge
11a
All 801,809,17x.x1 SAME
Frame, Discharge
11b
All 801,809,14x.x1 SAME
Rod, Hinge (Not Shown)
11c
All 801,401,70x.x1 SAME
Inner Door, Top Hinge, Weld Assembly
12
All 169,053,00x.x3 SAME
Inner Door, Bottom Hinge, Weld Assembly
13
All 169,051,10x.x3 SAME
INNER DOOR - MISCELLANEOUS
A1
Carriage Bolt ¼-20x¼ 800,202,43x.x1 SAME
A2
Screw,R, SD Phil Pan Sems (44) 800,304,23x.x1 SAME
A3
Inner Door Bushing (Bearing) 801,806,42x.x1 SAME
A4
Bushing Retainer 801,806,43x.x1 SAME
A5
Bearing,R, Plastic (Not Shown) (2) 901,803,71x.x1 SAME
Inner Door Lock Kit
A6
All 360,010,30x.x4 SAME
A7
Screw, 10-32x1/2 Machine Truss (4) 800,202,52x.x1 SAME
A8
Nut, KEPS #10-32 (4) 800,801,56x.x1 SAME
A9
Knob, Pull NA 901,501,70x.x1
A10
Bolt, Carriage 1/4-20x1 1/14 NA 800,202,43x.x1
Part number and description subject to change with out notice. NA = Not applicable TBD = To be determined RB = Replaced by
