PARTS LIST P SERIES
Page 79 of 100
HARNESSING Single Board (SBC)
ITEM
PART DESCRIPTION DN504P DN720P
Motor Harness (Stack)
1
All 000410 000596
Harness, P-Series Door
Chameleon 804,926,38x.x1 SAME
2
All LMV 804,926,37x.x1 SAME
Harness, MDB
Chameleon 804,919,58x.x1 SAME
3
All LMV 804,920,83x.x1 SAME
Harness, AC Distribution - Door
Chameleon 804,923,81x.x1 SAME
4
All LMV 804,923,80x.x1 SAME
Harness, Selection Panel
Chameleon 804,927,68x.x1 804,927,64x.x1
5
All LMV 804,921,09x.x1 804,921,08x.x1
66” DEX Harness
6
All 804,907,83x.x1 SAME
Secondary DEX Harness
7
All 804,913,97x.x1 SAME
Nut, DEX Harness
8
All 800,801,65x.x1 SAME
Display Harness (P3 to display board)
9
All 804,919,57x.x1 SAME
MDB and Lock Power Harness (P7)
Chameleon 804,919,58x.x1 SAME
10
All LMV 804,920,83x.x1 SAME
Extended Light Harness, AC Box
11
All 804,923,80x.x1 SAME
Power Cord, Detachable GFCI
All Except Italy 651,010,00x.x3 SAME
12
Italy 804,923,48x.x1 NA
HARNESSING - MISCELLANEOUS
A1
Label,R,Warning GFCI 803,885,18x.x1 SAME
A2
Label,R,Notice GFCI Equipped Machine 803,885,42x.x1 SAME
A3
Tie,R, Wire 7.5" 901,902,01x.x1 SAME
A4
Screw,R, 8-18x1/2 Phillip Pan 800,304,18x.x1 SAME
A5
Standoff,Reverse Lock 801,904,21x.x1 SAME
Part number and description subject to change with out notice. NA = Not applicable TBD = To be determined
RB = Replaced by
