TROUBLESHOOTING FLOWCHARTS P SERIES
Page 49 of 100
THE DISPLAY IS DEAD
Check the 1.6 or 1.0 fuse in
the Power Distribution Box.
Check continuity of the AC Power Harness from
the Control Board to the Power Distribution Box.
( J1 Connector of the Control Board )
To Next Page
