Dixie DN720P - PARTS LIST - MAIN DOOR EXTERIOR DETAILS; DN504 P & DN720 P Exterior Parts

PARTS LIST P SERIES
Page 57 of 100
MAIN DOOR EXTERIOR
ITEM
PART DESCRIPTION DN504P DN720P
Main Door Assembly P-Series - Specify Graphics
Chameleon 640,055,10x.x3 629,050,80x.x3
LMV 640,053,60x.x3 639,054,50x.x3
1
Italy 642,055,60x.x3 NA
Door Weld Assembly (Specify Color)
Chameleon 640,055,00x.x3 629,050,40x.x3
2
All LMV 642,053,50x.x3 642,053,60x.x3
Kit, Door Hinge
Chameleon 642,053,40x.x4 609,051,40x.x3
3
All LMV 642,053,40x.x4 SAME
Rain Guard
4
All 169,050,34x.x3 164,151,14x.x3
Trim,R, LMV
Right / Left 642,050,53x.x3 SAME
Top Transaction Panel 15.19" 642,050,56x.x3 SAME
Center Vertical 65.94" 642,050,54x.x3 SAME
Top / Bottom 34 1/8" 642,050,55x.x3 642,050,73x.x3
Side Full Length 80" 801,818,02x.x1 SAME
5
Center Full Length 80" 801,818,98x.x1 SAME
Trim,R, Chameleon
Top / Bottom Right Outer 12 3/8" 629,050,11x.x3 SAME
Enclosure - Coin Insert 15 11/16" 629,050,09x.x3 SAME
Center Outer 16 7/16" 629,050,13x.x3 SAME
Enclosure - Coin Return 7 3/8" 629,050,08x.x3 SAME
Left 801,809,67x.x1 SAME
Horizontal 801,809,65x.x1 801,809,67x.x1
Full Length Outer - 100 1/8" 801,810,17x.x1 SAME
6
Full Length Enclosure, Horizontal - 76 7/16" 801,809,68x.x1 SAME
Trim, Enclosure Top
7
Chameleon 801,805,81x.x1 SAME
Trim, Enclosure Bottom
8
Chameleon 801,805,82x.x1 SAME
Trim, Ad Panel
Chameleon 803,886,27x.x1 SAME
Bolt, Chameleon (3) 801,904,96x.x1 SAME
9
Nut, Chameleon (3) 801,904,97x.x1 SAME
Window, AD
10
All LMV 803,870,22x.x1 SAME
Card, AD
Coca-Cola 2008 805,044,08x.x1 SAME
Can, Spanish All 803,870,51x.x1 SAME
2008 Italy 805,044,35x.x1 NA
11
Dasani Lemon 805,042,31x.x1 SAME
Plate, Filler Bill Validator (Specify Color)
Chameleon 572,051,30x.x3 SAME
Red, LMV 624,050,93x.x3 SAME
12
Black, LMV 360,050,72x.x3 SAME
Gasket, Validator
13
All 802,001,22x.x1 SAME
Part number and description subject to change with out notice. NA = Not applicable TBD = To be determined RB = Replaced by
