Dixie DN720P - PARTS LIST - SELECT PANEL DETAILS; Select Panel Assembly Parts

PARTS LIST P SERIES
Page 70 of 100
.
SELECT PANEL
ITEM
PART DESCRIPTION DN504P DN720P
Select Panel Assembly
Chameleon 640,054,70x.x4 639,056,70x.x4
1
All LMV 642,051,70x.x3 642,051,60x.x3
Weld Assembly Select Panel - Not Shown
2
Only LMV 642,051,40x.x3 642,051,50x.x3
Select Switch
3
All 804,100,74x.x1 SAME
Select Button
Assy, Chameleon 805,202,83x.x1 SAME
4
All LMV 801,810,62x.x1 SAME
Nut, Selection Button
Housing, Selection Button
Spring, Selection Button
Insert, Selection Button
Washer, Selection Button Assembly
5
Holder, Selection Switch
Must order 805,202,83x.x1 Item 4
Select Button Bracket
Chameleon 800,102,82x.x1 SAME
6
All LMV 624,050,12x.x3 SAME
Sign Brace
7
Chameleon (2) NA 801,603,12x.x1
Harness
Chameleon 804,927,68x.x1 804,927,64x.x1
8
All LMV 804,921,09x.x1 804,921,08x.x1
Insulator,R, SII Switch
9
All LMV 801,812,17x.x1 SAME
Stop,R, Selection Button
10
All LMV 805,700,58x.x1 SAME
SELECT PANEL - MISCELLANEOUS
ITEM
PART DESCRIPTION DN504P DN720P
A1
Screw,R,4-24x3/4 Type B Phillip Pan 800,304,50x.x1 SAME
A2
Standoff, .187 x .312 x .625 901,001,44x.x1 SAME
A3
Hex Nut # 8 -32 800,801,54x.x1 SAME
A4
Screw, 6-20x11/32 (9) 800,305,28x.x1 SAME
A5
Rivet, Black Snap (24) 801,904,95x.x1 SAME
A6
Clamp, Nylon 1/2" 900,901,80x.x1 SAME
A7
Tape,R,PSA CLSD CELL 1RL= 1700ft 903,600,66x.x1 SAME
Part number and description subject to change with out notice.
NA = Not applicable TBD = To be determined RB = Replaced by
