PARTS LIST P SERIES
Page 75 of 100
ELECTRONIC COMPONENTS
ITEM
PART DESCRIPTION DN504P DN720P
Control Board Assembly SBC
1
All 640,010,00x.x3 SAME
Bracket, SBC Mounting
2
All LMV 642,050,09x.x3 642,050,11x.x3
Display Board 14 Segment
Chameleon 804,925,15x.x1 SAME
3
All LMV 804,925,16x.x1 SAME
Gasket, Display
4
All LMV 802,001,28x.x1 SAME
Transformer,R, Domestic CL2 UL1585
All Except Italy 804,925,96x.x1 SAME
5
Italy 804,926,90x.x1 NA
Controller Cover - Not Shown
6
All 801,306,16x.x1 SAME
EPROM (EPROM socket only shown)
7
All 804,919,77x.x1 SAME
Rain Curtain, Control Board
8
All 801,904,23x.x1 SAME
Battery, 3V Lithium (CR2032)
9
All 804,920,45x.x1 SAME
Door Switch
10
All 804,100,77x.x1 SAME
Cover, Display Board
11
Chameleon 801,809,99x.x1 SAME
Vend Sensor Assembly, Service Kit
12
All 639,010,00x.x3 SAME
ELECTRONIC COMPONENT - MISCELLANEOUS
A1
Kit, Override Switch 626,020,44x.x4 SAME
A2
Screw,R,#6-32x1/4" Pan Head Threadform (3) 800,202,48x.x1 SAME
A3
Screw,R,8-18x1/2 SD Phillip Pan 800,304,18x.x1 SAME
A4
Standoff,Reverse Lock (4) 801,904,21x.x1 SAME
A5
Label,R,Caution and Fuse S3D 803,857,06x.x1 SAME
A6
Ground,R,Wire 4" Green/Yellow 804,902,61x.x1 SAME
A7
Tie,R,Wire 7 1/2" 901,902,01x.x1 SAME
A8
Tape,R,Transparent, Adhesive Roll=108'
SH742
903,600,65x.x1 SAME
Part number and description subject to change with out notice.
NA = Not applicable TBD = To be determined RB = Replaced by
