Dixie DN720P - PARTS LIST - REFRIGERATION SYSTEM DETAILS; Refrigeration Components List

PARTS LIST P SERIES
Page 93 of 100
REFRIGERATION SYSTEM
ITEM
PART DESCRIPTION DN504P DN720P
A,R,Refrigeration Unit
All Except Italy 802,502,49x.x1 SAME
1
Italy 629,040,100.04 NA
Cord, Power Refrigeration Compressor
All Except Italy 802,401,85x.x1 SAME
2
Italy 804,925,74x.x1 NA
Blade, Fan Condenser
All Except Italy - 230mm Aluminum 802,401,84x.x1 SAME
3
Italy 801,306,65x.x1 NA
Motor, Condenser 9W
All Except Italy - 9W 115V/60Hz 802,401,83x.x1 SAME
4
Italy - 9W CW Morrill-SPD9HUB2 804,501,37x.x1 NA
Bracket, Condensor Fan Motor
5
Italy 639,040,05x.x3 NA
Bracket, Capacitor
All Except Italy 802,401,82x.x1 SAME
6
Italy 802,401,74x.x1 NA
Start Capacitor
All Except Italy 802,401,81x.x1 SAME
7
Italy 802,401,69x.x1 NA
Cover, Board, Terminal
All Except Italy 802,401,80x.x1 SAME
8
Italy 802,401,73x.x1 NA
Overload
All Except Italy - MRT 22AFZ-5590 802,401,79x.x1 SAME
9
Italy - TO741/G9 802,401,72x.x1 NA
Bracket, Overload
10
Italy 802,401,71x.x1 NA
Assy, Relay
All Except Italy 802,401,78x.x1 SAME
11
Italy 802,401,70x.x1 NA
Terminal, Board
All Except Italy 802,401,77x.x1 SAME
12
Italy NA NA
Assembly, Heat Exchanger 3000C-E
13
Italy 640,040,00x.x3 NA
Shroud, Condensor
14
Italy 640,040,02x.x3 NA
Tube, Discharge
15
Italy 640,040,04x.x3 NA
Accumulator,R, 1.375ODx6.000L
16
Italy 802,400,46x.x1 NA
Dryer,R, .054 Extended Outlet 134A
17
Italy 802,401,29x.x1 NA
Evaporator,R, Coil Short
18
Italy 802,600,37x.x1 NA
Condenser,R, 1.33 FPI 9x12.25x4
19
Italy 802,600,69x.x1 NA
Part number and description subject to change with out notice.
NA = Not applicable TBD = To be determined RB = Replaced by
