PARTS LIST P SERIES
Page 89 of 100
CHUTE ASSEMBLY
ITEM PART DESCRIPTION DN504P DN720P
Chute Assembly
Chameleon 640,072,00x.x3 639,072,80x.x3
1
All LMV 640,071,10x.x3 639,071,20x.x3
Chute
Chameleon 640,070,43x.x3 805,702,53x.x1
Export,LMV 640,070,41x.x3 639,070,52x.x3
2
Italy 640,070,43x.x3 NA
Liner, Chute
Chameleon 801,904,83x.x1 801,904,78x.x1
Export,LMV 801,904,73x.x1 801,904,71x.x1
3
Italy 801,904,83x.x1 NA
Vend Sensor Assembly, Service Kit
4
All 639,010,00x.x3 SAME
Support, Sensor Plate
Chameleon 640,070,36x.x3 639,070,33x.x3
5
All LMV 640,070,32x.x3 639,070,37x.x3
Vend Sensor Plate
Chameleon 640,070,37x.x3 639,070,34x.x3
6
All LMV 640,070,33x.x3 639,070,38x.x3
Cover, Sensor Housing
7
All 639,070,39x.x3 SAME
Housing, Vend Sensor
8
All 639,070,41x.x3 SAME
Board, Vend Sensor
9
All 804,925,26x.x1 SAME
Jumper, Vend Sensor
10
All 804,922,33x.x1 SAME
Lead, Vend Sensor Black
11
All 804,924,37x.x1 SAME
CHUTE ASSEMBLY MISCELLANEOUS
A1 Standoff (4) 801,904,55x.x1 SAME
A2 Rivet, 1/8" Black (2) 901,100,54x.x1 SAME
A3 Screw, 8-32x¼, Swage Form 800,304,34x.x1 SAME
A4 Rivet,R,1/8" Steel Zinc Plate (9) 801,100,81x.x1 SAME
A5 Screw, 8-32x¼ w/ washer 800,304,23x.x1 SAME
A6 Rivet, 1/8" Steel (9) 801,100,81x.x1 SAME
A7 Screw, 8-32x¼ w/ washer 800,304,23x.x1 SAME
Part number and description subject to change with out notice.
NA = Not applicable TBD = To be determined RB = Replaced by
