APPLICATION
This information applies to 504 and 720P-Series
venders manufactured the first quarter 2006 which
have significant differences in programming and
parts content from previous venders. To order parts
or information pertaining to this vender, please
contact Dixie Narco.
VENDER SAFETY PRECAUTIONS
Please read this manual in its entirety. This service
information is intended for use by a qualified service
technician, who is familiar with proper and safe
procedures to be followed when repairing, replacing,
or adjusting any Dixie-Narco vender components.
All repairs should be performed by a qualified
service technician who is equipped with the proper
tools and replacement components, using Genuine
Dixie-Narco Factory Parts.
REPAIRS AND/OR SERVICING
ATTEMPTED BY UNINFORMED
PERSONS CAN RESULT IN
HAZARDS DEVELOPING DUE TO
IMPROPER ASSEMBLY OR
ADJUSTMENTS WHILE
PERFORMING SUCH REPAIRS.
PERSONS NOT HAVING A PROPER
BACKGROUND MAY SUBJECT
THEMSELVES TO THE RISK OF
INJURY OR ELECTRICAL SHOCK
WHICH CAN BE SERIOUS OR EVEN
FATAL.
PRODUCT IDENTIFICATION
First production of 504 and 720 P-Series was March
2006.
The production date of Dixie-Narco products is
determined by the date code incorporated in the
serial number.
The vender serial number takes the form yyyyzz-
xxxx.The last 4 digits (xxxx) identify the specific
vender. The first 4 digits (yyyy) identify the
manufacturing run that the vender was built in. The
two alpha characters (zz) identify the quarter and the
year the vender was built. The first alpha-character
identifies the quarter.
A = 1st quarter
B = 2nd quarter
C = 3rd quarter
D = 4th quarter
The second alpha-character identifies the year:
E = 2006
F = 2007
G = 2008
H = 2009
I = 2010
J = 2011
PHYSICAL CHARACTERISTICS
720P 504P
HEIGHT
72” 72”
WIDTH
37” 28”
DEPTH
34” 33.5”
DEPTH WITH
VALIDATOR
N/A N/A
SHIPPING WEIGHT
788lbs 678 lbs.
Loaded Weight 4 Deep
Cans
1512lbs 1153 lbs
Model
Number of
Selections
Number of Narrow
Columns
504P
LMV
8 7
720P
LMV
8 10
504P
CCC
6 7
720P
CCC
8 10
RECEIVING INSPECTION
Upon receipt, inspect the vender for any shipping
damage. If there is any damage have the driver
note the damage on the bill of lading and notify
Dixie-Narco.
Although the terms of sale are FOB shipping point,
which requires the consignee to originate shipping
damage claims, Dixie-Narco will gladly help if you
must file a claim.
