Dixie DN720P - PARTS LIST - MAIN DOOR INTERIOR (A) MISCELLANEOUS; Interior (A) Miscellaneous Hardware

PARTS LIST P SERIES
Page 63 of 100
MAIN DOOR INTERIOR (A) - CONTINUED
ITEM
PART DESCRIPTION DN504P DN720P
Gasket, Validator
22
All 802,001,22x.x1 SAME
Door, Bill Validator VRV ( also coin box )
Chameleon 572,050,17x.x3 SAME
23
All LMV 642,050,01x.x3 SAME
Cover, T-Handle
24
All LMV 642,050,41x.x3 624,050,85x.x3
Cover, Wire Plug
Chameleon 640,050,07x.x3 SAME
25
All LMV 640,050,05x.x3 SAME
Bracket, Door Stop
26
All LMV 592,051,19x.x3 SAME
Door Stop, Black
27
All 631,051,26x.x3 SAME
Rod,R, Door
28
All LMV 801,402,86x.x1 801,402,85x.x1
Stiffener, Door Rod
29
All LMV 624,050,94x.x3 624,050,95x.x3
MAIN DOOR INTERIOR (A) MISCELLANEOUS
A1
Bolt,R, Carriage 1/4-20x1 800,202,42x.x1 SAME
A2
Bolt,R, Carriage 1/4-20x1 1/4 800,202,43x.x1 SAME
A3
Bolt,R, Carriage 1/4-20x1/2 800,202,45x.x1 SAME
A4
Carriage Bolt ¼ -20x 3/8 800,202,46x.x1 SAME
A5
Bolt,R, Carriage 1/4-20x3/4 800,202,47x.x1 SAME
A6
Screw,R,10-32x1/2 Machine Truss 800,202,52x.x1 SAME
A7
Bolt, Step 1/4-20x1 1/4 Black 800,202,53x.x1 SAME
A8
Bolt,R, Carriage 5/16-18x1 1/4 800,202,54x.x1 SAME
A9
Screw,R,8-189x1/2AB Phillip Pan SEM 800,304,09x.x1 SAME
A10
Screw,R,8-18x1/2 SD Phillips Pan 800,304,18x.x1 SAME
A11
Screw,R,8-32x3/8 Phillips Pan Type 1 800,304,22x.x1 SAME
A12
Screw,R,8-18x1/2 Phillip Pan SD SEM 800,304,23x.x1 SAME
A13
Screw,R, Tap 1/4-20x1 Hex Sems Type F 800,304,26x.x1 SAME
A14
Screw,R,1/4-20x5/8 Hex Type F 800,304,36x.x1 SAME
A15
Screw,R,8-18x3/4 Self Tapping 800,304,37x.x1 SAME
A16
Screw,R,6-20x3/8 SD Phillip Pan
800,304,77x.x1
SAME
A17
Bolt,R, T 8-32x3/4 800,400,61x.x1 SAME
A18
Bolt,R,T 8-32x1/2 800,400,62x.x1 SAME
A19
Washer,R, Flat 18Gauge 800,701,44x.x1 SAME
A20
Washer,R, Door Hinge 800,701,73x.x1 SAME
A21
Nut,R, KEPS 8-32 800,801,54x.x1 SAME
A22
Nut,R, Elastic Stop #8-32 800,801,55x.x1 SAME
A23
Nut,R, KEPS #10-32 800,801,56x.x1 SAME
A24
Hex nut ¼ - 20 800,801,57x.x1 SAME
A25
Nut,R,Hex 5/16-18 Center w/Flange 800,801,61x.x1 SAME
A26
Latch, Tablock Large Port 801,304,91x.x1 SAME
A27
Hole Plug, Black, 5/8" 801,903,36x.x1 SAME
A28
Bearing,R, Hinge Pinless 805,300,67x.x1 SAME
A29
Clip,R, Canoe 900,902,14x.x1 SAME
A30
Hole Plug,R, 5/16" HEYCO 2613 Black 900,902,15x.x1 SAME
Part number and description subject to change with out notice. NA = Not applicable TBD = To be determined RB = Replaced by
