Dixie DN720P - PARTS LIST - MAIN DOOR INTERIOR (B) DETAILS; DN504 P & DN720 P Interior (B) Parts

PARTS LIST P SERIES
Page 65 of 100
MAIN DOOR INTERIOR (B)
ITEM PART DESCRIPTION DN504P DN720P
Sub Assembly Coin Insert (Includes T Handle)
1
Chameleon 572,052,10x.x3 SAME
T-Handle Assembly Flush Mount
Chameleon 801,524,21x.x1 SAME
2
All LMV 801,525,64x.x1 SAME
Bracket, T-Handle
Chameleon - High Security 572,000,01x.x3 SAME
3
All LMV 642,050,41x.x3 624,050,85x.x3
Shield, T-Handle
4
All LMV 624,050,85x.x3 SAME
Shim, T-Handle Bracket
5
All LMV 805,701,24x.x1 SAME
Assembly, Coin Return
6
All LMV 642,054,20x.x3 SAME
Coin Return Bracket
Chameleon 572,050,24x.x3 SAME
7
LMV 624,051,23x.x3 SAME
Button, Push Coin Return
8
All 801,807,25x.x1 SAME
Bracket, Coin Return Rocker
9
LMV 624,051,26x.x3 SAME
Coin Return Rocker
Chameleon 572,050,22x.x3 SAME
10
All LMV 642,050,66x.x3 SAME
Roller Pin
Chameleon 800,503,78x.x1 SAME
11
All LMV 800,503,78x.x1 SAME
Roller Pin Retainer
12
All 900,900,90x.x1 SAME
Coin Return Spring
Chameleon 901,700,63x.x1 SAME
13
All LMV 901,700,63x.x1 801,701,22x.x1
Plunger, Coin Return / Extension
Chameleon 572,050,23x.x3 SAME
14
All LMV 642,050,67x.x3 SAME
Geometry (red lens)
Chameleon 801,807,22x.x1 SAME
LMV 801,810,67x.x1 SAME
Large Coin, Export 801,807,23x.x1 SAME
15
Italy 801,810,67x.x1 SAME
Coin Insert Chute Cover Clear
16
Chameleon 801,805,80x.x1 SAME
Coin Insert Chute Clear
17
Chameleon 801,805,79x.x1 SAME
Part number and description subject to change with out notice.
NA = Not applicable TBD = To be determined RB = Replaced by
